Panasonic PT-MZ880BD

Well-Balanced Picture Quality
Tuned for Optimal Brightness and Colour

Refined optical engine delivers an ideal balance of high brightness and vivid colour for clear visibility in well-lit rooms. With a selection of display modes optimized to suit different kinds of content and screen surfaces and dynamic optimization technologies that continuously adjust the image to suit environment and content, your audience will enjoy comfortably visible pictures without turning the room lights off.

Flexible Design Fits Any Space
Unobtrusive Cabinet Blends into the Room

Elegant new cabinet styling helps these projectors blend into the room environment. Use of black for the recessed base makes the side and front panels appear slimmer. By combining unobtrusive styling with quiet operation and clear image visibility, the projection (not the projector) becomes the focus of attention. All-black versions are available for easy concealment in dark environments, such as museums.

Efficient Eco-Friendly Reliability
Low Maintenance 20,000-hour Operation

Projector maintenance is recommended at about 20,000 hours to reduce time, cost, and effort to your organization. Long-life laser light-source eliminates hassles associated with lamp disposal (which sometimes contain specified toxic substances) and reduces your consumable parts inventory.

Reduced Waste with Lamp-free Design and Eco Filter

Eco Filter includes a Micro Cut Filter that collects minute dust particles with an electrostatic effect. Together with dust-resistant projector cabinet, Eco Filter enables long-term use in dusty conditions with less downtime. Replacement is at about 20,000 hours, and the filter can be washed and reused. And thanks to the projector’s long-life laser light-source, there’s no hassles associated with lamp disposal.

Projector type LCD projectors
LCD panel | Panel size (mm) 19.3 mm diagonal (16:10 aspect ratio)
LCD panel | Panel size (inch) 0.76 inch diagonal (16:10 aspect ratio)
LCD Panel | Display Method Transparent LCD panel (x 3, R/G/B)
LCD Panel | Drive Method Active matrix
LCD Panel | Pixels 2,304,000 ( Pixels 1920 x 1200) pixels x 3
Light Source Laser diodes
Light Output 8,000 lm
Resolution WUXGA (1920 x 1200 pixels)
Contrast Ratio 3,000,000:1 (Full On/Full Off) (When [PICTURE MODE] is set to [DYNAMIC] and [DYNAMIC CONTRAST] is set to [1] or [2]. HDMI signal input)

Screen size (diagonal) (mm) 1.02–10.16 m (40–400 in), 1.52–10.16 m (60–400 in) with the ET-ELW22, 2.54–10.16 m (100–400 in) with the ET-ELU20, 16:10 aspect ratio
Screen size (diagonal) (inch) 1.02–10.16 m (40–400 in), 1.52–10.16 m (60–400 in) with the ET-ELW22, 2.54–10.16 m (100–400 in) with the ET-ELU20, 16:10 aspect ratio
Center-to-corner zone ratio*1 85 %
Lens Powered zoom (throw ratio 1.61–2.76:1), powered focus F = 1.7–2.3, f = 26.8–45.5 mm (for supplied lens; optional lenses also available)

Lens shift | Vertical(From the origin point of the lens mounter) ±67 % (powered) (for supplied lens; optional lenses also available*4)
Lens shift | Horizontal(From the origin point of the lens mounter) ±35 % (powered) (for supplied lens; optional lenses also available*4)
Keystone Correction Range Vertical: ±25 °, Horizontal: ±30 ° (for supplied lens; optional lenses also available*4)
Installation Ceiling/floor, front/rear, free 360-degree installation

Terminals | HDMI In HDMI 19-pin x 3 (Compatible with HDCP 2.3, Deep Color, 4K/60p*5 signal input), CEC supported
Terminals | Computer In D-sub HD 15-pin (female) x 1 (RGB/YPBPR/YCBCR)
Terminals | Monitor Out D-sub HD 15-pin (female) x 1 (RGB/YPBPR/YCBCR)
Terminals | Serial / Multi Sync In D-sub 9-pin (female) x 1 for external control/link control (RS-232C compliant)
Terminals | Multi Sync Out D-sub 9-pin (male) x 1 for link control
Terminals | REMOTE 1 IN M3 stereo mini-jack x 1 for wired remote control
Terminals | Remote 2 In D-sub 9-pin (female) x 1 for external control (parallel)
Terminals | Audio In M3 stereo mini-jack x 1
Terminals | Audio Out M3 stereo mini-jack x 1
Terminals | DIGITAL LINK RJ-45 x 1 for network and DIGITAL LINK connection (video/network/serial control) (HDBaseT™ compliant), 100Base-TX (Compatible with PJLink™ [Class 2], Art-Net, HDCP 2.3, Deep Color,4K/60p*5 *6 signal input)
Terminals | LAN RJ-45 x 1 for network connection, 10Base-T, 100Base-TX (Compatible with PJLink™ [Class 2], Art-Net)
Terminals | DC Out USB Connector (Type A) x 1 (Output 5 V/2 A)

Power Supply AC 100–240 V, 50/60 Hz
Power Consumption*7 | Maximum power consumption 360 W (4.2–2.0 A) (395 VA)(Power consumption is 345 W at 200–240 V)

Power Consumption*7 | On-mode power consumption (Light power) [NORMAL]: 330 W (100–120 V), 315 W (200–240 V)[ECO]: 240 W (100–120 V), 230 W (200–240 V)[QUIET]: 238 W (100–120 V), 228 W (200–240 V)
Cabinet Materials Molded plastic
Filter Included (Estimated maintenance time: approx. 20,000 hours)

Operation noise*1 32 dB (NORMAL/ECO), 26 dB (QUIET)
Dimensions (W × H*8 × D) 561 x 224 x 439 mm (22 3/32˝ x 8 13/16˝ x 17 9/32˝ ) (with supplied lens)
Weight*9 Approx. 17.6 kg (38.8 lbs) (with supplied lens)

Operating Environment Operating temperature: 0–45 °C (32–113 °F)*10, operating humidity: 20–80 % (no condensation)
Applicable software/application Logo Transfer Software, Multi Monitoring & Control Software, Early Warning Software, Smart Projector Control for iOS/Android™, Geometry Manager Pro*11
